IM 972-2 • MAVERICK I ROOFTOP SYSTEMS 12 www.DaikinApplied.com

Figure 10: Heat Exchanger Component Identication
Figure 11: Honeywell VR8305Q4120 Two Stage Gas Valve
OUTLET PRESSURE
TAP-1/8 NPT
2-STAGE
OPERATOR
INLET PRESSURE
TAP-1/8 NPT
GROUND
TERMINAL
LOW STAGE ADJUSTMENT
UNDER VENT CAP
HIGH STAGE ADJUSTMENT
UNDER VENT CAP
