Daikin MPS025B - Physical Data - Auxiliary Heater Kits (600 V); Auxiliary Heater Kit Performance

IM 972-2 • MAVERICK I ROOFTOP SYSTEMS 26 www.DaikinApplied.com

Table 15: Auxiliary Heater Kits Characteristics and Application: 600V — 3 Phase
Unit Model Number
MPS
Heater Kit
Model No. RXJJ
Heater Kw @ 600V Heater Kit Fla Unit Min. Ckt. Ampacity
Max. Fuse or Ckt. Bkr. Size
(Ckt. Bkr. Must Be HACR
Type For USA)
015 Low Static Drive
NONE — — 28 35
CE20Y 19.2 18.5 28 35
CE40Y 38.4 37 51 60
CE60Y 57.6 55.4 74 80
CE75Y 72 69.3 92 100
015 High Static Drive
NONE — — 30 35
CE20Y 19.2 18.5 30 35
CE40Y 38.4 37 53 60
CE60Y 57.6 55.4 76 80
CE75Y 72 69.3 94 100
020 Low Static Drive
NONE — — 40 50
CE20Y 19.2 18.5 40 50
CE40Y 38.4 37 53 60
CE60Y 57.6 55.4 76 80
CE75Y 72 69.3 94 100
020 High Static Drive
NONE — — 42 50
CE20Y 19.2 18.5 42 50
CE40Y 38.4 37 56 60
CE60Y 57.6 55.4 80 80
CE75Y 72 69.3 97 100
025 Low Static Drive
NONE — — 47 60
CE20Y 19.2 18.5 47 60
CE40Y 38.4 37 53 60
CE60Y 57.6 55.4 76 80
CE75Y 72 69.3 94 100
025 High Static Drive
NONE — — 50 60
CE20Y 19.2 18.5 50 60
CE40Y 38.4 37 59 60
CE60Y 57.6 55.4 82 90
CE75Y 72 69.3 100 100
