Daikin MPS025B - Dimensional Data - Unit Dimensions (Gas Heat); Unit Dimensions MPS 015 B - 025 B

IM 972-2 • MAVERICK I ROOFTOP SYSTEMS 28 www.DaikinApplied.com

Figure 24: MPS 0015B – 025B Dimensions (Gas Heat)
– DISCONNECT
– OUTLET
– POWER
– LOW VOLTAGE
OPTIONAL HORIZONTAL
SUPPLY CONNECTION
OPTIONAL HORIZONTAL
RETURN CONNECTION
RETURN
[3863 mm]
152
KNOCKOUT LOCATIONS
SUPPLY
CONTROL PANEL/FILTER
ACCESS DOOR
CONDENS
ATE DRAIN
(1 [25.4 mm] FNPT)
OPTIONAL OUTDOOR
HOOD LOCATION
FAN
ACCESS DOOR
