IM 962-2 3
Introduction
Introduction
Hazard Identication Information
DANGER
The use of unauthorized components, accessories or devices
may adversely affect the operation of the condensing unit and
may also endanger life and property.
The manufacturer disclaims any responsibility for such loss
or injury and the manufacturer’s warranty does not cover
any damage or defect to the air conditioner caused by the
attachment or use of any components, accessories or devices
(other than those authorized by the manufacturer) into, onto
or in conjunction with the condensing unit.
DANGER
Dangers indicate a hazardous situation which will result in
death or serious injury if not avoided.
WARNING
Warnings indicate potentially hazardous situations, which
canresult in property damage, severe personal injury, or death
ifnot avoided.
CAUTION
Cautions indicate potentially hazardous situations, which can
result in personal injury or equipment damage if not avoided.
This manual contains the installation and operating
instructions for your split condensing unit. There are a
few precautions that should be taken to derive maximum
satisfaction from it. Improper installation can result in
unsatisfactory operation or dangerous conditions.
Read this manual and any instructions packaged with separate
equipment required to make up the system prior to installation.
Give this manual to the owner and explain its provisions. The
owner should retain this manual for future reference.
Checking Product Received
Upon receiving the unit, inspect it for any damage from
shipment. Claims for damage, either shipping or concealed,
should be led immediately with the shipping company.
Check the unit model number, electrical characteristics, and
accessories to determine if they are correct.
Nomenclature
NOTE: For larger size units (greater than 20 ton), refer to Catalog 222.
R C S – 06 – F – 078 – C
Rooftop Condensing System
Nominal capacity (tons)
06 = 6.5
07 = 7.5
10 = 10 (single compressor)
11 = 10 (tandem compressors)
12 = 12
15 = 15
20 = 20
Refrigerant
F = R-410A
Voltage
C = 208/230 - 3 - 60
D = 460 - 3 - 60
Y = 575 - 3 - 60
Compressor
078 = 6.5 ton, single
090 = 7.5 ton, single
120 = 10 ton, single
125 = 10 ton, tandem
150 = 12.5 ton, tandem
180 = 15 ton, tandem
240 = 20 ton, tandem
