8 IM 962-2
Physical Data
Physical Data
Unit Capacity and Physical Data
Table 5: RCS 06F – 20F Physical Data
Model
RCS
06F Single 07F Single 10F Single 11F Tandem 12F Tandem 15F Tandem 20F Tandem
Capacity and Weight
Capacity (tons) [kW] 6.5 [22.9] 7.5 [26.4] 10 [35.2] 10 [35.2] 12 [42.2] 15 [52.8] 20 [70.3]
Number of circuits 1
Operating weight
(lbs) [Kg]
291 [132] 318 [144] 501 [227.3] 586 [265.8] 650 [294.8] 746 [338.4] 952 [431.8]
Shipping weight
(lbs) [Kg]
314 [142.5] 341 [154.7] 541 [245.4] 626 [284.0] 690 [313.0] 786 [356.5] 992 [450.0]
Compressor
Quantity 1 2
Type Scroll
RPM 3500
Refrigerant charge
R410A oz. [g]
178 [5046] 242 [6861] 339 [9661] 300 [8505] 378 [10,716] 506 [14,345] 655 [18,569]
Condenser Fans
Quantity 1 2 3
CFM [L/s] 4700 [2218] 4700 [2218] 8100 [3822] 8100 [3822] 8100 [3882] 12,000 [5663] 12,000 [5663]
Diameter (in.) [mm 24 [610] 24 [610] 24 [610] 24 [610] 24 [610] 24 [610] 24 [610]
Drive Direct
Motor horsepower
each [W]
1/3 [249] 1/3 [249] 1/3 [249] 1/3 [249] 1/3 [249] 1/3 [249] 1/3 [249]
Type PSC
RPM 1075
Condenser Coil
Quantity 1 2
Rows 1-1/2 2 3
Fins per inch 20 22 18 22 22 22 22
Sq. ft. [m
2
] 23.0 [2.14] 23.0 [2.14] 27.0 [2.51] 27.0 [2.51] 33.9 [3.05] 40.38 [3.75] 40.38 [3.75]
Fins/tubes Aluminum/Copper
Cabinet
Finish Powder Coat
Sheet metal Galvanized
Gauge (nominal) top 20
Sides 20
Base rails 14
Refrigerant Connection
Vapor sweat (in.) [mm] 1-1/8 [29] 1-1/8 [29] 1-3/8 [35] 1-3/8 [35] 1-3/8 [35] 1-5/8 [41.3] 1-5/8 [41.3]
Liquid sweat (in.) [mm] 1/2 [13] 1/2 [13] 5/8 [16] 5/8 [16] 5/8 [16] 5/8 [16] 7/8 [22]
