Introduction: Unit Description
Figure 4. Component locations—RDT units
Evaporator coils
Optional back return
air opening
Filter section
Optional outside &
return air dampers
Power entrances 3" dia K.O.
Control entrances 7/8" dia K.O.
Bottom return opening
1.50 MPT drain
Bottom supply air opening
Outside air louvers
(both sides)
Return air fan
Exhaust dampers
Return air plenum
DX coil section
Supply fan section
Side View
Top View
