Removal of Oute
r Panels (Pa
ttern 2)
Si001169
12
Removal Proc
edure
4.
Remove the ri
ght si
de
panel.
1
Remove the 5 screws.
2
Sli
de the ri
ght
side
panel downward to
unfast
en the 2 hooks on
the back s
ide.
3
Remove the right
side
panel.
Step
Procedure
Points
(R16621)
Right
side
panel
(R9688)
Hook
(R16622)
(R16623)
13
15
