13 Technical data
A subset of the latest technical data is available on the regional Daikin website
(publicly accessible). The full set of latest technical data is available on the Daikin
Business Portal (authentication required).
13.1 Overview: Technical data
This chapter contains information about:
• Service space
• Piping diagram
• Wiring diagram
• Information requirements for Eco Design
13.2 Service space: Outdoor unit
Suction side In the illustrations below, the service space at the suction side is based on 35°CDB and
cooling operation. Foresee more space in the following cases:
▪ When the suction side temperature regularly exceeds this temperature.
▪ When the heat load of the outdoor units is expected to regularly exceed the maximum
operating capacity.
Discharge side Take refrigerant piping work into account when positioning the units. If your layout does
not match with any of the layouts below, contact your dealer.
Single unit ( ) | Single row of units ( )
