Daikin Super Multi NX B series User Manual

Si12-308 Instruction
System Configuration 121
■
Remote Controller
1. Signal transmitter:
•
It sends signals to the indoor unit.
2. Display:
•
It displays the current settings.
(In this illustration, each section is shown with all
its displays ON for the purpose of explanation.)
3. HOME LEAVE button:
for HOME LEAVE operation
4. POWERFUL button:
for POWERFUL operation
5. TEMPERATURE adjustment buttons:
•
It changes the temperature of time setting.
6. ON/OFF button:
•
Press this button once to start operation.
Press once again to stop it.
7. MODE selector button:
•
It selects the operation mode.
(AUTO/DRY/COOL/HEAT/FAN)
8. SILENT button:
for OUTDOOR UNIT
SILENT operation
9. FAN setting button:
• It selects the air flow rate setting.
10. SENSOR button:
for INTELLIGENT EYE
operation
11. SWING button
•
Flap (Horizontal blade)
12. SWING button
•
Louver (Vertical blades)
13. ON TIMER button
14. OFF TIMER button
15. TIMER Setting button:
• It changes the time setting.
16. TIMER CANCEL button:
• It cancels the timer setting.
17. CLOCK button
C
ON
TEMP
ON/OFF
POWERFUL
HOME LEAVE
MODE
TIMER
FAN
SILENT SWING
ON CANCEL
OFF
SENSOR
1
2
5
6
9
11
10
12
16
17
13
15
14
< ARC433A21, A22 >
3
4
7
8
