Si12-308 Instruction
System Configuration 155
1. Open the front grille.
2. Pull out the air filters.
•
Push a little upwards the tab at the center of
each air filter, then pull it down.
3. Take off the air purifying filter
with photocatalytic deodorizing function.
• Press the top of the air-cleaning filter onto the tabs
(3 tabs at top). Then press the bottom of the filter up
slightly, and press it onto the tabs (3 at bottom).
4.
Clean or replace each filter.
See below.
5. Set the air filter, air purifying filter with
photocalytic deodorizing function as they
were and close the front grille.
•
Press the front panel at both sides and the center.
■
Air Filter
1.
Wash the air filters with water or clean them with vacuum cleaner.
•
If the dust does not come off easily, wash them with neutral detergent
thinned with lukewarm water, then dry them up in the shade.
•
It is recommended to clean the air filters every two weeks.
■
Air purifying filter with photocatalytie deodorizing function. (gray)
The air purifying capacity of the photocatalytic purifying filter can be renewed by washing it with
water once every 6 months. We recommend replacing it once every 3 years.
[ Maintenance ]
1. Remove dust with a vacuum cleaner and wash lightly with water.
2.
If it is very dirty, soak it for 10 to 15 minutes in water mixed with a neutral cleaning agent.
3. After washing, shake off remaining water and dry in the shade.
4.
Since the material is made out of paper, do not wring out the filter when removing water from it.
[ Replacement]
1. Remove the tabs on the filter frame and replace with a new filter.
• Dispose of the old filter as flammable waste.
Filters
tabs (3 tabs at top)
tabs (3 at bottom)
To Next Page
