Si12-308 Specifications
Specifications 25
60Hz 220V
Model FTKD71BVMT
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 16.6 (586)
M 13.9 (491)
L 11.7 (413)
SL 10.4 (367)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof
Running Current (Rated) A 0.23
Power Consumption (Rated) W 50
Power Factor % 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimension mm 1,147×366×337
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
