Si12-308 Specifications
Specifications 27
230V, 50Hz
Model FTKS71BVMB
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 16.7 (590)
M 14.2 (501)
L 11.6 (409)
SL 10.6 (374)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof
Running Current (Rated) A 0.20
Power Consumption (Rated) W 45
Power Factor % 96.4
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimension mm 1,147×366×337
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
15.9
Drain mm
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
