Specifications Si12-308
30 Specifications
Duct Connected Type
230V, 50Hz
Model CDKS25BVMB CDKS35BVMB
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color
——
Air Flow Rates
m³/min
(cfm)
H 12.7 (448) 13.0 (459)
M 11.7 (413) 12.0 (424)
L 10.7 (378) 11.0 (388)
SL 9.0 (318) 9.3 (328)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 47 47
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.40 0.40
Power Consumption (Rated) W 85 85
Power Factor % 92.4 92.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 260×900×580 260×900×580
Packaged Dimension mm 1,070×719×354 1,070×719×354
Weight kg 23 23
Gross Weight kg 32 32
Operation
Sound
H/M/L/SL dBA 39/37/36/33 39/37/36/33
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
27.2 (3/4B)
φ
27.2 (3/4B)
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model CDKS50BVMB CDKS60BVMB
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color
——
Air Flow Rates
m³/min
(cfm)
H 13.0 (459) 14.5 (512)
M 12.0 (424) 13.0 (459)
L 11.0 (388) 11.5 (406)
SL 10.1 (357) 10.2 (360)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 47 47
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.40 0.45
Power Consumption (Rated) W 85 95
Power Factor % 92.4 91.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 260×900×580 260×900×580
Packaged Dimension mm 1,070×719×354 1,070×719×354
Weight kg 24 24
Gross Weight kg 33 33
Operation
Sound
H/M/L/SL dBA 42/40/39/36 44/42/41/38
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
27.2 (3/4B)
φ
27.2 (3/4B)
