Specifications Si12-308
42 Specifications
50Hz 220V
Model
FTXD71BVMC
Cooling Heating
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 18.0 (635) 19.8 (700)
M 15.1 (533) 17.1 (602)
L 12.7 (448) 14.4 (510)
SL 11.3 (399) 12.6 (446)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.23 0.23
Power Consumption (Rated) W 50 50
Power Factor % 98.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (W×D×H) mm 1,147×366×337
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34 46/42/37/34
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
