Specications
General Data
Model UAL160A5 UAL210A5
Nominal cooling capacity
208V~230V/3Ph/60Hz
kW/
Btu/h
59/ 201365 72/ 245734
460V/3Ph/60Hz
59/ 201365 72/ 245734
380V/3Ph/60Hz
56/ 191127 72/ 245734
Rate cooling input power
208V~230V/3Ph/60Hz
kW
20.2 25
460V/3Ph/60Hz
20.2 25
380V/3Ph/60Hz
19.4 25
EER
208V~230V/3Ph/60Hz
Btu/h/W
12.2 9.83
460V/3Ph/60Hz
12.2 9.83
380V/3Ph/60Hz
9.8 9.83
Rated running current
208V~230V/3Ph/60Hz
A
64.1 81.5
460V/3Ph/60Hz
32.7 40
380V/3Ph/60Hz
39 50
Power supply
208V~230V/380V/460V/3Ph/60Hz
Refrigerant
Type
R410A
Charge kg
6.5 ×2 8.5 ×2
Water ow
208V~230V/3Ph/60Hz
m
3
/h
9.13 11.1
460V/3Ph/60Hz
9.13 11.1
380V/3Ph/60Hz
8.67 11.1
WPD (Water Pressure
Drop)
208V~230V/3Ph/60Hz
kPa
142 73
460V/3Ph/60Hz
142 73
380V/3Ph/60Hz
128 73
Unit dimensions
(L x W x H)
208V~230V/3Ph/60Hz
mm/in.
1820×1059×1853/72×42×73 2056×1140×2193/80.9×44.9×86.3
460V/3Ph/60Hz
1820×1059×1853/72×42×73 2056×1140×2193/80.9×44.9×86.3
380V/3Ph/60Hz
1820×1059×2012/72×42×79 2056×1140×2193/80.9×44.9×86.3
Packing dimensions
(L x W x H)
208V~230V/3Ph/60Hz
mm/in.
1820×1059×1853/72×42×73 2056×1140×2193/80.9×44.9×86.3
460V/3Ph/60Hz
1820×1059×1853/72×42×73 2056×1140×2193/80.9×44.9×86.3
380V/3Ph/60Hz
1820×1059×2012/72×42×79 2056×1140×2193/80.9×44.9×86.3
Net weight
208V~230V/3Ph/60Hz
kg/lb
615/1355 730/1609
460V/3Ph/60Hz
615/1355 730/1609
380V/3Ph/60Hz
640/1410 730/1609
Operating weight
208V~230V/3Ph/60Hz
kg/lb
630/1388 745/1642
460V/3Ph/60Hz
630/1388 745/1642
380V/3Ph/60Hz
655/1443 745/1642
Gross weight
208V~230V/3Ph/60Hz
kg/lb
616/1357 731/1611
460V/3Ph/60Hz
616/1357 731/1611
380V/3Ph/60Hz
641/1412 731/1611
NOTES:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
NOMINAL COOLING CAPACITY IS BASED ON LEAVING WATER TEMPERATURE 6.7°C, AMBIENT TEMPERATURE 35°C AND 0.043 L/S
PER KW WATER FLOW.
