Daikin UAL-A Series User Manual

6
Electrical Data
Model UAL160A5 UAL210A5
Fan motor
Rated running current
208V~230V/3Ph/60Hz
A
4.5×2 6.5×2
460V/3Ph/60Hz
2.2×2 2.6×2
380V/3Ph/60Hz
4×2 4×2
Motor output W
1000×2 1000×2
Poles
6 8
Fan speed
208V~230V/3Ph/60Hz
RPM
910 910
460V/3Ph/60Hz
910 840
380V/3Ph/60Hz
690 690
Compressor
Rated running current
208V~230V/3Ph/60Hz
A
32.9 45.7
460V/3Ph/60Hz
17.9 19.2
380V/3Ph/60Hz
21.4 26.4
Locked rotor AMP (LRA)
208V~230V/3Ph/60Hz
A
267 304
460V/3Ph/60Hz
142 147
380V/3Ph/60Hz
160 168
IP/ Insulation grade
IPX4/E IPX4/E
Unit operating current
208V~230V/3Ph/60Hz
A
64.1 81.5
460V/3Ph/60Hz
32.7 40
380V/3Ph/60Hz
39 50
Unit max running current
208V~230V/3Ph/60Hz
A
79.1 103
460V/3Ph/60Hz
38.6 50
380V/3Ph/60Hz
49.1 65
NOTES:
1. ALL SPECIFICTIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2. MAX RUNNING CURRENT IS TESTED UNDER BELOW CONDITION: COOLING OUTDOOR DRY-BULB TEMPERATURE 43°C, HEATING
DRY-BULB TEMPERATURE 21°C, WET-BULB TEMPERATURE 15.5°C.
3. THE RATED RUNNING CURRENT ARE TESTED AT THE HIGH SPEED AND LOW SPEED.
Safety Devices
Model UAL160A5 UAL210A5
Safety device
High pressure switch
Type
PSW,H20PS B PSW,H20PS B
Open MPa
4.15 ± 0.1 4.15 ± 0.1
Close MPa
3.11 ± 0.1 3.11 ± 0.1
Low pressure switch
Type
N/A N/A
Open MPa
N/A N/A
Close MPa
N/A N/A
Phase sequencer
YES YES
Discharge temperature setting °C/°F
130/266 130/266
NOTE:
1. ALL SPECIFICTIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

Daikin UAL-A Series Specifications

General

Refrigerant	R-410A
Compressor Type	Scroll
Type	Air-cooled scroll chiller
Power Supply	400V, 50Hz, 3 Phase (Varies by model, check specific model)
Dimensions	Varies by model
Weight	Varies by model
