SiUS30-604 Field Setting
Test Operation 99
3. Field Setting
3.1 Field Setting from Remote Controller
Individual function of indoor unit can be changed from the remote controller. At the time of
installation or after service inspection / repair, make the local setting in accordance with the
following description.
Wrong setting may cause malfunction.
(When optional accessory is mounted on the indoor unit, setting for the indoor unit may be required
to change. Refer to information in the option handbook.)
3.1.1 Wired Remote Controller <BRC1C71>
1. When in the normal mode, push the button for 4 seconds or more, and operation then
enters the “field set mode”.
2. Select the desired “mode No.” with the button.
3. During group control and you want to set by each individual indoor unit (when mode No. 20, 21,
22, 23, 25 has been selected), push the time mode button and select the “indoor unit
No.” to be set.
Note: This operation is not required when setting as a group.
4. Push the button and select the first code No.
5. Push the button and select the second code No.
6. Push the timer button one time and “define” the currently set contents.
7. Push the button to return to the normal mode.
(Example)
When setting the filter sign time to “Filter Dirtiness-High” in all group unit setting, set the Mode No.
to “10”, Mode setting No. to “0” and setting position No. to “02”.
To Next Page
