Specifications SiUS30-604
16 Specifications
1. Specifications
1.1 Outside Units
Notes:
1.
★
1 Indoor temp. : 80°FDB, 67°FWB / inlet water temp. : 85°F / outlet water temp. : 95°F
Equivalent piping length : 25ft, level difference : 0ft.
★
2 Indoor temp. : 70°FDB, 60°FWB / inlet water temp. : 70°F / Equivalent piping length : 25ft, level difference : 0ft.
★
3 In the case of heat pump system, suction gas pipe is not used.
★
4 In the case of heat recovery system.
★
5 In the case of heat pump system.
2. This unit cannot be installed outdoors.
Install indoors (Machine room etc.).
3. Hold ambient condition at 35~95°F, ~80%RH
Heat rejection from the casing : 0.64kW
4. There are some cases where capacity decreases depending on operating states.
Model Name RWEYQ60MTJU
★
1 Cooling Capacity Btu / h 60,000
★
2 Heating Capacity Btu / h 67,500
Casing Color Ivory White (5Y7.5/1)
Dimensions: (H×W×D) in 39-3/8×30-3/4×21-11/16
Heat Exchanger Stainless Steel Plate Type
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 9.21
Number of Revolutions r.p.m 4,350
Motor Output×Number
of Units
kW 3.2
Starting Method Soft Start
Connecting
Pipes
Liquid Pipe in 3/8 in C1220T (Flare Connection)
Suction Gas Pipe in 3/4 in C1220T (Brazing Connection)
★3
Discharge Gas Pipe in
★4 5/8 in C1220T, ★5 3/4 in C1220T (Brazing Connection)
Water inlet 1 1/4 FPT Female Thread
Water outlet 1 1/4 FPT Female Thread
Drain outlet 1/2 FPS Female Thread
Machine Weight (Mass) Lbs 330
Sound Level (Reference Value) dBA 50
Safety Devices High Pressure Switch, Inverter Overload Protector, Fusible Plugs
Capacity Control % 23~100
Refrigerant
Refrigerant Name R-410A
Charge Lbs 9.9
Control Electronic Expansion Valve
Refrigerator Oil Synthetic (Ether) Oil
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps, Strainer, Conduit Mounting Plate
Drawing No. 4D054570D
