Daikin VRV - WII User Manual

SiUS30-604 Field Setting
Test Operation 103
3.1.5 Applicable range of Field setting
∗
1 Static pressure selection
3.1.6 Detailed Explanation of Setting Modes
Filter Sign Setting
If switching the filter sign ON time, set as given in the table below.
Set Time
Ultra-Long-Life Filter Sign Setting
When a Ultra-long-life filter is installed, the filter sign timer setting must be changed.
Setting Table
Ceiling
mounted
cassette type
Slim Ceiling
mounted duct
type
Ceiling
mounted
built-in type
Ceiling
mounted duct
type
Ceiling
Suspended
type
Wall mounted
type
Floor
standing type
Concealed
Floor
standing type
Multi flow
FXFQ FXSQ FXMQ FXHQ FXAQ FXLQ FXNQ
Filter sign {{{{{{{{
Ultra long life filter sign { ———————
Remote controller
thermostat sensor
{{{{{{{{
Set fan speed when
thermostat OFF
{{{{{{{{
Air flow adjustment Ceiling
height
{ ———{ ———
Air flow direction { ———————
Air flow direction
adjustment
(Down flow operation)
————————
Air flow direction
adjustment range
{ ———————
Field set fan speed
selection
{{
∗1— —
{
———
Filter Specs.
Setting
Standard Long Life Ultra Long Life Filter
Contamination Light 200 hrs. 2,500 hrs. 10,000 hrs.
Contamination Heavy 100 hrs. 1,250 hrs. 5,000 hrs.
Mode No. Setting Switch No. Setting Position No. Setting
10 (20) 1
01 Long-Life Filter
02 Ultra-Long-Life Filter (1)
03 —
