HXHD125A7V1B
VRVIII system indoor unit
4PW62585-1 – 11.2010
Operation manual
20
9 Automatic temperature compensation
00 Installation related setting
(a)
0 –2~2 0.2 °C
01 Installation related setting
(a)
0 –5~5 0.5 °C
02 Installation related setting
(a)
0 –5~5 0.5 °C
03 Not applicable. Do not change the default value. 0 — — —
04 Not applicable. Do not change the default value. 0 — — —
A Option setup
00 Installation related setting
(a)
00~21—
01 Not applicable. Do not change the default value. 0 — — —
02 Installation related setting
(a)
10 5~15 1 °C
03 Installation related setting
(a)
35 25~80 1 °C
04 Installation related setting
(a)
65 25~80 1 °C
b Domestic hot water set points
00 Set point: reheat minimum temperature 35 35~65 1 °C
01 Set point: reheat maximum temperature 45 35~75 1 °C
02 Status: weather dependent domestic water
heating
1 (ON) 0/1 — —
03 Set point: storage temperature 70 45~75 1 °C
04 Automatic maximum domestic hot water storage
temperature
70 55~75 1 °C
C Leaving water temperature limits
00 Installation related setting
(a)
80 37~80 1 °C
01 Installation related setting
(a)
25 25~37 1 °C
02 Not applicable. Do not change the default value. 20 — — —
03 Not applicable. Do not change the default value. 5 — — —
04 Not applicable. Do not change the default value. 0 — — —
d Domestic water heating retention times
00 Installation related setting
(a)
10 5~20 1 —
01 Installation related setting
(a)
30 10~60 5 —
02 Installation related setting
(a)
15 5~30 5 —
03 Not applicable. Do not change the default value. 15 — — —
04 Not applicable. Do not change the default value. 40 — — —
E Service mode
00 Installation related setting
(a)
00/1——
01 Not applicable. Do not change the default value. 0 — — —
02 Not applicable. Do not change the default value. 0 — — —
03 Not applicable. Do not change the default value. 1 — — —
04 Installation related setting
(a)
00~21—
F Option setup continued
00 Not applicable. Do not change the default value. 5 — — —
01 Not applicable. Do not change the default value. 0 — — —
02 Installation related setting
(a)
10~21—
03 Not applicable. Do not change the default value. 10 — — —
04 Not applicable. Do not change the default value. 50 — — —
(a) For more information about installation related setting, see installation manual of the indoor unit. For settings different from the default value, contact your installer.
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
