Daintree GE Current WA100-PM User Manual

Installation GuideDaintree
®
Networked Wireless Adapter (WA100-PM)
17
15
Wiring for Combination Plug Load (Aux Relay with
Input Control Signal) and Dimming Light
Inthewiringdiagrambelow,theWA100-PMisusedto
controlbothadimminglightandaplugloadcircuit.
Plug Load Applications Continued
Perform Installation Test Suite 1
DIP Switches
Driver:
On/Off+0-10V
dimming. Plug
LoadOn/Off
WiredSensor:
None
On
1 2 3 4 5 6
(#2,3 On)
OFF
ON
*0-10VDimmingoutput,5mAavailable,Upto10LEDdriversor
 uorescentballaststypical;thechanceofnoiseonthesignal
increases with more.
**RelaysusedtocontrolplugloadsmustbecompliantwithUL498
(Attachment Plug and Receptacles) or equivalant.
