Installation GuideDaintree
®
Networked Wireless Adapter (WA100-PM)
9
Figure 13: Switching a Branch Circuit
ThiscongurationallowstheWA100-PMtoprovideOn/Off
switchingofabranchcircuit.
Figure 14: 208V 2-Pole (Phase-to-Phase) wiring
ThiscongurationallowstheWA100-PMtoprovideOn/Off
switchingofabranchcircuit.
7
Wiring Continued
OFF
ON
OFF
ON
Perform Installation Test Suite 1
DIP Switches
DriverType:
On/Off
(no dimming)
WiredSensor:
None
On
1 2 3 4 5 6
(#4 ON)
Perform Installation Test Suite 1
DIP Switches
DriverType:
On/Off
(no dimming)
WiredSensor:
None
On
1 2 3 4 5 6
(#4 ON)
