Dake Euromatic 370 S - Page 46

0 3
0
4 5 6 7 8 9
7
A A
B B
0 0
F
-
-
2020074
Item
Type
Description
Manufacturer
Board
Sh
Qty
CP1
2.100.110.061
PIECE COUNTER TYPE BVa15.11 24 VAC 50/60HZ 119mA
FR ITZ KUBLER GMBH
6
FU1 5450124
1421004
PMX 10X3 UR FUSE 3P
CH10 GG 4A FUSIBILE 10,3X38MM
Wimex
IT AL WEBER
3
1
3
FU2 5450121
1421002
PMX 10X1 UR FUSE HOLDER 1P
CH10 GG 2A FUSE10,3X38MM
Wimex
IT AL WEBER
3
HL4 Luminous signaling
3
KA1 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmu11er
Weidmuller
4
KA10 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
7
KA11 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
7
KA2 7760056101
7760056 107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmu11er
Weidmuller
5
KA3 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmu11er
Weidmuller
5
KA4 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
6
KA5 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmu11er
Weidmuller
6
KA6 7760056101
7760056 10 7
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmu11er
Weidmuller
6
KA7 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
6
KA8 7760056101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
6
KA9 7760056 101
7760056107
D-SERIES DRM, relay, Number of contacts: 4, Changeover contact with test button, AgNi 0.15 µm Au, Rated Voltage: 24 V AC, Continuous current 10 A, Plug-in connection
D-SERIES DRM, Relay socket, Number of Contacts: 4, Changeover contact, Current: 12 A, Screw Connection
Wei dmuller
Weidmuller
7
KM1
3RT20261AC20
CONT.11KW,1L+1R,AC 24V 50/60HZ,SO VT
Siemens
=QG
5
KM2
3RT20151AB01
CONTJKW,1L,AC 24 V,SOO VT
Siemens
=QG
5
Q1
NL T32/3V /Z33/Z45
SWITCH DISCONNECT 32A-3P BOTTOM PANEL, SELF CENTERING LOCK
SONTHEIMER
=QG
2
QF1
3RV20214BA 10
INT.AUT.SO, 14-20A,VT
Siemens
=QG
3
RT1
850200240000
7760056107
TIMED RELAY
D-SERIES DRM, Relay socket, Number of contacts: 4, Changeover contact, Current 12A, Screw connection
Finder
Weidmuller
=QG 5
RT2 850200240000
7760056107
TIMED RELAY
D-SERIES DRM, Relay socket, Number of contacts: 4, Changeover contact, Current 12A, Screw connection
Finder
Weidmuller
6
RT3 850200240000
7760056107
TIMED RELAY
D-SERIES DRM, Relay socket, Number of contacts: 4, Changeover contact, Current 12A, Screw connection
Finder
Weidmuller
6
RT4 850200240000
7760056107
TIMED RELAY
D-SERIES DRM, Relay socket, Number of contacts: 4, Changeover contact, Current 12A, Screw connection
Finder
Weidmuller
7
SA6
ZB4BD2
ZB4BZ101
Black selector head for unit 022 with 2 fixed positions
Single body contact block/1NO contacts with spring terminals
Schneider Electric
Schneider Electric
3
T1
26000200.144
Single Phase Transformer Sic F-Ul 160Va P 160VA 0.230.400 S 160VA 0.24
Tecnocablaggi
3
1
XM 1608620000
1010200000
Modular passage terminal ZOU 6
Modular terminal block and protective conductor WPE 6
Weidmuller
Weidmuller
6
B
ILL OF MATERIAL
