Dake V-40 - Page 17

4/29/03
Manual V-16, V-24, VH-24, V-40 & VH-40 17 – Section I
MATERIAL ALLOY 1/2" 1" 2" 4" 7" 12"
1100,2011,2017,2024 fpm 568 sipm 7 fpm 577 sipm 11 fpm 536 sipm 16 fpm 498 sipm 21 fpm 451sipm 23 fpm 389 sipm 24
ALUMINUM ALLOY 3003,5052,5086,6061 fpm 568 sipm 7 fpm 577 sipm 11 fpm 536 sipm 16 fpm 498 sipm 21 fpm 451sipm 23 fpm 389 sipm 24
6063,6101,6262,7075 fpm 568 sipm 7 fpm 577 sipm 11 fpm 536 sipm 16 fpm 498 sipm 21 fpm 451sipm 23 fpm 389 sipm 24
356,360 fpm 511 sipm 7 fpm 501 sipm 10 fpm 482 sipm 14 fpm 448 sipm 19 fpm 406 sipm 21 fpm350 sipm 22
353 fpm 454 sipm 6 fpm 445 sipm 8 fpm 429 sipm 12 fpm 399 sipm 17 fpm 361 sipm 19 fpm311 sipm 19
1452,187 fpm 426 sipm 6 fpm 418 sipm 8 fpm 402 sipm 12 fpm 374 sipm 16 fpm 338 sipm 18 fpm 292 sipm 18
380,544 fpm 397 sipm 5 fpm 390 sipm 7 fpm 375 sipm 11 fpm349 sipm 15 fpm 316 sipm 16 fpm 272 sipm 17
173,932 fpm 358 sipm 5 fpm 351 sipm 7 fpm 338 sipm 10 fpm 314 sipm 13 fpm 284 sipm 15 fpm 245 sipm 15
330,365 fpm 324 sipm 4 fpm 317 sipm 6 fpm 305 sipm 9 fpm 284 sipm 12 fpm 257 sipm 13 fpm 222 sipm 14
COPPER ALLOY 623,624 fpm 301 sipm 4 fpm 295 sipm 6 fpm 284 sipm 8 fpm 264 sipm 11 fpm 239 sipm 12 fpm 206 sipm 13
230,260,272 fpm 278 sipm 4 fpm 273 sipm 5 fpm 263 sipm 8 fpm 244 sipm 10 fpm 221 sipm 11 fpm 191 sipm 12
280,464,632,655 fpm 278 sipm 4 fpm 273 sipm 5 fpm 263 sipm 8 fpm 244 sipm 10 fpm 221 sipm 11 fpm 191 sipm 12
101,102,110,122,172 fpm 267 sipm 3 fpm 262 sipm 5 fpm 252sipm 7 fpm 234 sipm 10 fpm 212 sipm 11 fpm 183 sipm 11
1751,182,220,510 fpm 267 sipm 3 fpm 262 sipm 5 fpm 252 sipm 7 fpm 234 sipm 10 fpm 212 sipm 11 fpm 183 sipm 11
625,706,715,934 fpm 267 sipm 3 fpm 262 sipm 5 fpm 252 sipm 7 fpm 234 sipm 10 fpm 212 sipm 11 fpm 183 sipm 11
630 fpm 261 sipm 3 fpm 256 sipm 5 fpm 246 sipm 7 fpm 229 sipm 10 fpm 207 sipm 11 fpm 179 sipm 11
811 fpm 244 sipm 3 fpm 239 sipm 5 fpm 230 sipm 7 fpm 214 sipm 9 fpm 194 sipm 10 fpm 167 sipm 10
12L14 fpm 483 sipm 6 fpm 473 sipm 9 fpm 455 sipm 13 fpm 424 sipm 18 fpm 383 sipm 20 fpm 321 sipm 20
1213,1215 fpm 454 sipm 6 fpm 445 sipm 8 fpm 429 sipm 12 fpm 399 sipm 17 fpm 361 sipm 19 fpm 311 sipm 19
RESULFURIZED 1117 fpm 386 sipm 5 fpm 379 sipm 7 fpm 364 sipm 11 fpm 339 sipm 15 fpm 307 sipm 16 fpm 265 sipm 16
CARBON STEEL 1137 fpm 329 sipm 4 fpm 323 sipm 6 fpm 311 sipm 9 fpm 289 sipm 12 fpm 262 sipm 14 fpm 262 sipm 14
1141,1144 fpm 318 sipm 4 fpm 312 sipm 6 fpm 300 sipm 9 fpm 279 sipm 12 fpm 253 sipm 13 fpm 218 sipm 13
1144 HI STRESS fpm 318 sipm 4 fpm 312 sipm 6 fpm 300 sipm 9 fpm 279 sipm 12 fpm 253 sipm 13 fpm 218 sipm 13
1030 fpm 375 sipm 5 fpm 367 sipm 7 fpm 254 sipm 10 fpm 329 sipm 14 fpm 298 sipm 15 fpm 257 sipm 16
1008,1015,1020,1025 fpm 363 sipm 5 fpm 356 sipm 7 fpm 343 sipm 10 fpm 319 sipm 14 fpm 289 sipm 15 fpm 249 sipm 15
1035 fpm 352 sipm 5 fpm 345 sipm 7 fpm 332 sipm 10 fpm 309 sipm 13 fpm 280 sipm 14 fpm 241 sipm 14
1018,1021,1025 fpm 341 sipm 4 fpm 334 sipm 6 fpm 321 sipm 9 fpm 299 sipm 13 fpm 271 sipm 14 fpm 234 sipm 14
CARBON STEEL 1026,1513 fpm 341 sipm 4 fpm 334 sipm 6 fpm 321 sipm 9 fpm 299 sipm 13 fpm 271 sipm 14 fpm 234 sipm 14
A36 (SHAPES),1040 fpm 307 sipm 4 fpm 301 sipm 6 fpm 289 sipm 8 fpm 269 sipm 12 fpm 243 sipm 13 fpm 210 sipm 13
1042,1541 fpm 284 sipm 4 fpm 278 sipm 5 fpm 268 sipm 8 fpm 249 sipm 11 fpm 225 sipm 12 fpm 195 sipm 12
1044,1045 fpm 250 sipm 3 fpm 245 sipm 5 fpm 236 sipm 7 fpm 219 sipm 9 fpm 198 sipm 10 fpm 171 sipm 11
1060 fpm 227sipm 3 fpm 223 sipm 4 fpm 214 sipm 6 fpm 199 sipm 9 fpm 180 sipm 9 fpm 156 sipm 10
1095 fpm 210 sipm 3 fpm 206 sipm 4 fpm 198 sipm 6 fpm 184 sipm 8 fpm 167 sipm 9 fpm 144 sipm 9
8615,8620,8622 fpm 273 sipm 4 fpm 267 sipm 5 fpm 257 sipm 7 fpm 239 sipm 10 fpm 216 sipm 11 fpm 187 sipm 12
NI-CR-MO 4340,E4340,8630 fpm 250 sipm 3 fpm 245 sipm 5 fpm 236 sipm 7 fpm 219 sipm 9 fpm 198 sipm 10 fpm 171 sipm 11
ALLOY STEEL 8640 fpm 227 sipm 3 fpm 223 sipm 4 fpm 214 sipm 6 fpm 199 sipm 9 fpm 180 sipm 9 fpm 156 sipm 10
E9310 fpm 199 sipm 3 fpm 195 sipm 4 fpm 188 sipm 5 fpm 174 sipm 7 fpm 158 sipm 8 fpm 136 sipm 8
TOOL STEEL L-6 fpm 216 sipm 3 fpm 212 sipm 4 fpm 204 sipm 6 fpm 189 sipm 8 fpm 171 sipm 9 fpm 148 sipm 9
SHOCK RESISTING S-1 fpm 227 sipm 3 fpm 223 sipm 4 fpm 214 sipm 6 fpm 199 sipm 9 fpm 180 sipm 9 fpm 156 sipm 10
TOOL S-5 fpm 159 sipm 2 fpm 156 sipm 3 fpm 150 sipm 4 fpm 140 sipm 6 fpm 126 sipm 7 fpm 109 sipm 7
STEEL S-7 fpm 142 sipm 2 fpm 139 sipm 3 fpm 134 sipm 4 fpm 125 sipm 5 fpm 113 sipm 6 fpm 97 sipm 6
