122 • Operational Reference Nano Series GigE Vision Camera
Reset Mode – Exposure Timing Specifications
For single and multi-frame reset mode exposures, the following timing values of different Sony
models are specified in the following table. Refer to the previous graphics.
Variable Sony Models Timing Value
a
all 0 µsec
b
all 0 µsec + plus any user set ExposureDelay
c
M/C810 12x horizontal line time (in µsec) – 4.997 µsec
c
M/C700 & M/C1450 17x horizontal line time (in µsec) - 14.26 µsec
c
M/C1920 & M/C1940 Reset Exposure Not Supported
c
M/C1950 10x horizontal line time (in µsec) – 13.73 µsec
c
M/C2020 & M/C2420 10x horizontal line time (in µsec) – 13.73 µsec
c
M/C2050 & M/C2450 12x horizontal line time (in µsec) - 13.73 µsec
c
M/C4020 & M/C4030 10x horizontal line time (in µsec) - 14.26 µsec
c
M/C4040 & M/C4060 23x horizontal line time (in µsec) - 14.26 µsec
d
M810 Minimum: Readout + 12x horizontal line time (in µsec) – 4.997 µsec
d
M/C700 & M/C1450 Minimum: Readout + 17x horizontal line time (in µsec) - 14.26 µsec
d
M/C1920 & M/C1940 Reset Exposure Not Supported
d
M/C1950 Minimum: Readout + 10x horizontal line time (in µsec) – 13.73 µsec
d
M/C2020 & M/C2420 Minimum: Readout + 10x horizontal line time (in µsec) – 13.73 µsec
d
M/C2050 & M/C2450 Minimum: Readout + 12x horizontal line time (in µsec) – 13.73 µsec
d
M/C4020 & M/C4030 Minimum: Readout + 10x horizontal line time (in µsec) - 14.26 µsec
d
M/C4040 & M/C4060 Minimum: Readout + 23x horizontal line time (in µsec) - 14.26 µsec
Additional Exposure Features
Additional triggered exposure mode features and timing are described in the I/O Controls Category.
Refer to Model Part Numbers for the available Nano models using Sony sensors and their timing
specifications.
