14 d&b Q-Series

The Qi rigging system

Safety approval

d&b loudspeakers and accessories are designed for set up and

use within situations requiring compliance with the provisions

and directives of BGV C1 Rule for the Prevention of Accidents.

Z5172

Qi-SUB

Mounting plate

Z5171

Qi Mounting plate

Z5170

Qi Mounting adapter

Z5160

Q Load adapter

WLL: 480 kg/1058 lb

or 20 Qi1 loudspeakers;

aiming of a column by 1/1,

1/2 or 1/4 detents

Z5147

Rota clamp

WLL: 500 kg/1100 lb;

for a tube diameter up to

51 mm/2”

Z5145

Ci/Qi Mounting frame

WLL: 240 kg/530 lb

e.g. nine Q loudspeakers
