Rail heat control
The rail heat can be controlled in several ways:
0: The function is not used
1: Pulse control is used with a timer function following the day/night operation
(o41 and o42)
2: Pulse control is used with a dew point function. This function requires that a signal
is received about the dew point value. The value is measured by a system manager
and sent to the controller via the data communication.
o85 Railh. mode
Dew point value where the rail heat is minimum
This function is discussed earlier in the manual.
o86 DewP Min lim
Dew point value where the rail heat is maximum
This function is discussed earlier in the manual.
o87 DewP Max lim
Lowest permitted rail heat eect
Here the % part of the eect to be achieved when the dew point value is minimum.
o88 Rail Min ON%
Start of refrigeration when door is open
If the door has been left open, refrigeration must be started after a set time. That time
can be set here.
o89 DoorInjStart
Fan operation for forced closing
If “forced closing” is activated, it will aect the operation of the fan and the defrosting.
Select the desired settings:
0: The fans will stop. Defrosting permitted.
1: The fans will run. Defrosting permitted.
(For 0 and 1: If the “forced closing” signal comes during a defrosting cycle,
or if a new defrosting cycle begins, the fans will follow the setting in d09.)
2: The fans will stop. Defrosting not permitted.
3: The fans will run. Defrosting not permitted.
(For 2 and 3: If the “forced closing” signal interrupts a defrosting cycle
but disappears again within 10 minutes, the defrosting cycle will resume.)
o90 Fan forcedCl
Alternative display
A reading can be displayed by pressing the lower button on the controller. This
reading is set from the factory so that the defrosting stop temperature is displayed.
A dierent setting will give the following reading:
1: (Defrost stop temperature = factory setting)
2: S6 temperature
o92 Displ menu 2
Display of temperature during normal operation
1: Air temperature. Weighted S3 + S4
2: Product temperature S6
o97 Disp. Ctrl.
Light and night blinds denition
0: Light is switched o and night blinds are open when the main switch is o
1: Light and night blinds are independent of main switch.
o98 Light MS = O
Conguration of alarm relay
The alarm relay will be activated upon an alarm signal from the following groups:
0 - No relay function
1 - High temperature alarms
2 - Low temperature alarms
4 - Sensor error
8 - Digital input enabled for alarm
16 - Defrosting alarms
32 - Miscellaneous
64 - Injection alarms
128 - Disconnected fuse
The groups that are to activate the alarm relay must be set by using a numerical value
which is the sum of the groups that must be activated.
(E.g.: a value of 5 will activate all high temperature alarms and all sensor error.
P41 Al.Rel.Conf.
Digital input signal - DI4. Switch signal. See DI3 above P55 DI4 cong.
Digital input signal - DI5. Switch signal. See DI3 above P56 DI5 cong.
Digital input signal - DI6. Switch signal. See DI3 above P57 DI6 cong.
Digital input signal - DI7. High voltage signal. Functions the same as those
for DI3, but signal is 0 V/230 V. See also the summary on page 12.
P58 DI7 cong.
Digital input signal - DI8. High voltage signal. See DI7 above P59 DI8 cong.
Max. opening time for night blind after manual DI activation
The delay time before the night blind automatically goes down again after being
manually opened for product stocking.
P60 BlindOpenTim
Reset settings on ID module
Reset all settings so that the ID module can receive settings from another controller.
P61 ResetID Mem.
Conguration of night blind function
On= night blind function used. O=night blind function not used.
P64 Blind cong
