28 User Guide RS8GR602 © Danfoss 2016-10 AK-CT 450A
Fan pause while night blind rolls down
Here you can set the fan pause time, so the night blind can roll down unhindered
to the correct position.
P65 BlindFanStop
Max. on time for light after manual DI activation
Delay time before light goes o again after light has been turn on manual due to
product stocking.
P66 Light On Time
Case shutdown
Service Service
Temperature measured with S5 sensor u09 S5 temp.
Status on DI1 input. on/1=closed u10 DI1 status
Read the duration of the ongoing defrost or the duration of the last completed
defrost.
u11 Defrost time
Temperature measured with S3 sensor u12 S3 air temp
Status at the day-/night operation (night operation: on/o) u13 Night Cond.
Temperature measured with S4 sensor u16 S4 air temp
Thermostat temperature u17 Ther. air
Read the ongoing cutin time for the thermostat or the duration of the last
completed cutin
u18 Ther runtime
Read the valve’s actual opening degree u23 Valve OD %
Read the temperature at the S6 sensor u36 S6 temp
Status on DI2 input. on/1=closed u37 DI2 status
Air temperature. Weighted S3 + S4 u56 Display air
Measured temperature for alarm thermostat u57 Alarm air
* Status on relay for cooling u58 Comp1/LLSV
Status on relay for fan u59 Fan relay
* Status on relay for defrost u60 Def. relay
Status on relay for railheat u61 Railh. relay
* Status on relay for alarm
u62 Alarm relay
Status on relay for light u63 Light relay
* Status on relay for hot gas valve u64 SuctionValve
* Status on relay for compressor 2 u67 Comp2 relay
* Temperature measured with S5B sensor
u75 S5 temp. B
* Temperature measured with S3B sensor
u76 S3 air temp B
* Temperature measured with S6B sensor
u79 S6 temp. B
* Status on relay for hot gas
u80 Hotgas valve
* Status on relay for heating element in drip tray
u81 Drip tray
* Status on relay for night blinds
u82 Blinds relay
* Status on relay for defrost 2
u83 Def. relay 2
* Readout of the actual rail heat eect in %
u85 Rail DutyC %
Readout of which thermostat used for regulation: 1= Thermostat 1,
2= Thermostat 2
u86 Ther. band
Status on input DI3 (closed / open)
u87 DI3 status
Readout of the actual cutin value for the thermostat
u90 Cutin temp.
Readout of the actual cut out value for the thermostat
u91 Cutout temp.
* Measured temperature for alarm thermostat for B section
U34 Alarm air B
* Air temperature. Weighted S3 + S4 temp. for B section
U35 Display air B
* Status of relay for light 2 U36 Extra light
* Status of relay for ECO fan U37 Fan Eco
* Status of relay for defrost 3 U38 Def. relay 3
Status of DI4 input. On=closed U39 DI4 status
Status of DI5 input. On=closed U40 DI5 status
Status of DI6 input. On=closed U41 DI6 status
Status of high-voltage input DI7, 230 V = 1 = closed U42 DI7 status
Status of high voltage input DI8, 230 V = 1 = closed U43 DI8 status
0-10 V output indicates EVR valve’s degree of opening U44 AO1 voltage
