36 User Guide RS8GR602 © Danfoss 2016-10 AK-CT 450A
Continued Code 1 2 3 4 5 6 7 8 Min. Max. Fac. Actual
Max hold time after coordinated defrost o16 1 1 1 1 1 1 1 1 0 min. 360 min. 20
Select signal for display view. S4% (100%=S4, 0%=S3) o17 1 1 1 1 1 1 1 1 0 % 100 % 100
Input signal on DI2. Function:
0=not used. 1=status on DI2. 2=door function with alarm
when open. 3=door alarm when open. 4=defrost start
(pulse signal). 5=ext. main switch. 6=night operation
7=thermostat band changeover (activate r21). 8=alarm function
when closed. 9=alarm function when open. 10=case cleaning
(pulse signal). 11=forced cooling at hot gas defrost, 12=night
cover.13=coordinated defrost). 14=forced close. 15=appliance
shutdown. 16=light. 17=extra light. 18=cancel defrost.
19=override light.
o37 1 1 1 1 1 1 1 1 0 19 0
Conguration of light function: 1=Light follows day/night opera-
tion, 2=Light control via data communication via ‘o39’, 3=Light
control with a DI-input, 4=As with “2”, but light switch on and
night cover will open if the network cuts out for more than
15 minutes. 5=Light goes on when a signal is received from both
DI and central signal (DI7 or data communication). 6=Like “5”,
but light also goes on for manual activation of night blind.
o38 1 1 1 1 1 1 1 1 1 6 1
Activation of light relay (only if o38=2, 5 or 6)
o39 1 1 1 1 1 1 1 1 0/O 1/On 0/O
Rail heat On time during day operations
o41 1 1 1 1 1 1 1 1 0 % 100 % 100
Rail heat On time during night operations
o42 1 1 1 1 1 1 1 1 0 % 100 % 100
Rail heat period time (On time + O time)
o43 1 1 1 1 1 1 1 1 1 min. 60 min. 10
Case cleaning. 0=no case cleaning. 1=Fans only. 2=All output O.
*** o46 1 1 1 1 1 1 1 1 0 2 0
Select application. See overview page 13 to 16 * o61 1 1 1 1 1 1 1 1 1 8 1
Access code 2 (partial access) *** o64 1 1 1 1 1 1 1 1 0 100 0
Replace the controllers factory settings with the present settings
o67 1 1 1 1 1 1 1 1 0/O 1/On 0/O
Input signal on DI3. Function:
(0=not used. 1=status on DI3. 2=door function with alarm when
open. 3=door alarm when open. 4=defrost start (pulse-signal).
5=ext. main switch 6=night operation, 7=thermostat band
changeover (activate r21). 8=Not used. 9=Not used. 10=case
cleaning (pulse signal). 11=forced cooling at hot gas defrost,
12=night cover. 13=Not used. 14=Refrigeration stopped (forced
closing). 15=appliance shutdown. 16=light. 17=extra light.
18=cancel defrost. 19=override light.
o84 1 1 1 1 1 1 1 1 0 19 0
Rail heat control
0=not used, 1=pulse control with timer function (o41 and o42),
2=pulse control with dew point function
o85 1 1 1 1 1 1 1 1 0 2 0
Dew point value where the rail heat is minimum
o86 1 1 1 1 1 1 1 1 -10°C 50°C 8
Dew point value where the rail heat is 100% on
o87 1 1 1 1 1 1 1 1 -9°C 50°C 17
Lowest permitted rail heat eect in %
o88 1 1 1 1 1 1 1 1 0 % 100 % 30
Time delay from "open door” refrigeration is started
o89 1 1 1 1 1 1 1 1 0 min. 240 min. 30
Fan operation on stopped refrigeration (forced closing):
0: The fans will be stopped and defrosting will be permitted.
1: The fans will run and defrosting will be permitted.
2: The fans will be stopped and defrosting will not be permitted.
3: The fans will run and defrosting will not be permitted.
o90 1 1 1 1 1 1 1 1 0 3 1
Denition of readings on lower button:
1=defrost stop temperature, 2=S6 product temperature,
o92 1 1 1 1 1 1 1 1 1 2 1
Display of temperature
1= u56 Air temperature
2= u36 product temperature
o97 1 1 1 1 1 1 1 1 1 2 1
Light and night blinds dened
0: Light is switch o and night blind is open when the main
switch is o
1: Light and night blind is independent of main switch
o98 1 1 1 1 1 1 1 1 0 1 0
Conguration of alarm relay
The alarm relay will be activated upon an alarm signal from
the following groups:
1 - High temperature alarms
2 - Low temperature alarms
4 - Sensor error
8 - Digital input enabled for alarm
16 - Defrosting alarms
32 - Miscellaneous
64 - Injection alarms
128 - Fuse cut out
The groups that are to activate the alarm relay must be set by
using a numerical value which is the sum of the groups that
must be activated.
(E.g.: a value of 5 will activate all high temperature alarms and
all sensor error.
P41
1 1 1 1 1 1 1 1
0 255 239
Input signal on DI4. Switch signal. See DI3 above P55
1 1 1 1 1 1 1 1
0 19 0
To Next Page
