12 Instructions RI8PR102 © Danfoss 6/2012 AK-CC 550A - 084B8070
Continued Code 1 2 3 4 5 6 7 8 9 10 Min. Max. Fac. Actual
*) Can only be set when regulation is stopped (r12=0)
**) Can be controlled manually, but only when r12=-1
***) With access code 2 the access to these menus will be limited
Factory settings are indicated for standard units. Other code numbers
have customized settings.
Service
Temperature measured with S5 sensor
u09 1 1 1 1 1 1 1 1 1 1
Status on DI1 input. on/1=closed
u10 1 1 1 1 1 1 1 1 1 1
Actual defrost time (minutes)
u11 1 1 1 1 1 1 1 1 1 1
Temperature measured with S3 sensor
u12 1 1 1 1 1 1 1 1 1 1
Status on night operation (on or o) 1=on
u13 1 1 1 1 1 1 1 1 1 1
Temperature measured with S4 sensor
u16 1 1 1 1 1 1 1 1 1 1
Thermostat temperature
u17 1 1 1 1 1 1 1 1 1 1
Run time of thermostat (cooling time) in minutes
u18 1 1 1 1 1 1 1 1 1 1
Temperature of evaporator outlet temp.
u20 1 1 1 1 1 1 1 1 1 1
Superheat across evaporator
u21 1 1 1 1 1 1 1 1 1 1
Reference of superheat control
u22 1 1 1 1 1 1 1 1 1 1
Opening degree of AKV valve
** u23 1 1 1 1 1 1 1 1 1 1
Evaporating pressure Po (relative)
u25 1 1 1 1 1 1 1 1 1 1
Evaporator temperature To (Calculated)
u26 1 1 1 1 1 1 1 1 1 1
Temperature measured with S6 sensor
(product temperature)
u36 1 1 1 1 1 1 1 1 1
Status on DI2 output. on/1=closed
u37 1 1 1 1 1 1 1 1 1 1
Air temperature . Weighted S3 and S4
u56 1 1 1 1 1 1 1 1 1 1
Measured temperature for alarm thermostat
u57 1 1 1 1 1 1 1 1 1 1
Status on relay for cooling
** u58 1 1 1 1
Status on relay for fan
** u59 1 1 1 1 1 1 1 1 1 1
Status on relay for defrost
** u60 1 1 1 1 1 1 1 1 1
Status on relay for rail heat
** u61 1 1 1 1 1 1 1
Status on relay for alarm
** u62 1 1 1 1 1
Status on relay for light
** u63 1 1 1 1 1 1 1 1
Status on relay for valve in suction line
** u64 1
Status on relay for compressor 2
** u67 1
Temperature measured with S5B sensor
u75 1
Status on relay for hot gas- / drain valve
** u80 1
Status on relay for heating element in drip tray
** u81 1
Status on relay for night blinds
** u82 1
Status on relay for defrost B
** u83 1
Status on relay for heat function
** u84 1
Readout of the actual rail heat eect
u85 1 1 1 1 1 1 1
1: Thermostat 1 operating, 2: Thermostat 2 operating
u86 1 1 1 1 1 1 1 1 1 1
Status on high voltage input DI3
u87 1 1 1 1 1 1 1 1 1 1
Readout of thermostats actual cut in value
u90 1 1 1 1 1 1 1 1 1 1
Readout of thermostats actual cut out value
u91 1 1 1 1 1 1 1 1 1 1
Readout of status on the adaptive defrost
0: O. Function is not activated and are zero set
1: Sensor error or S3/S4 are reversed.
2: Tuning is in progress
3: Normal
4: Light build-up of ice
5: Medium build-up of ice
6: Heavy build-up of ice
U01 1 1 1 1 1 1 1 1 1 1
Number of defrosts carried out since the initial power
up or since the resetting of the function
U10 1 1 1 1 1 1 1 1 1 1
Number of defrosts skipped since the initial power up
or since the resetting of the function
U11 1 1 1 1 1 1 1 1 1 1
