Danfoss AME 110 NLX

© Danfoss | 2017.01 | 3
VI.HU.D2.02
AME 110 NLX
❹
❻
50
92
88
68
Type
L H b
mm ISO 228/1
DN 10 109 138 G ½
DN 15 116 141 G ¾
DN 20 125 143 G 1
DN 25 142 155 G 1 ¼
DN 32 160 166 G 1 ½
Reset
①
②
③
④
ON
OFF
0-10 V INV SEQ 5-10 V LOG ASTX I
2-10 V
DIR
---
0-5 V
LIN
---
U
H
L
AME 110 NLX +
AB-QM DN 10-32
b
