Service guide | Disassembling and Assembling, A
PP(W) 5
.
1-
1
0.
2
© Danfoss | DCS (im) | 2017.06
180R9238 | DKCFN.PI.078.F3.02 | 521B1196 | 7
2.
Mount the spacer on the swash plate
.
1.
Replace the O-rings.
3.
Remove the swash plate and the spac
er
.
3.
Position the swash pla
te on the mounting
flange using the guide pins and fix it with
the screw
.
4.
The mounting flange is now ready t
o be
mounted on the housing.
4.
Assembling swash plate
6
8
