3. Notes
1. Correct wiring is essential; using instrument to con-
rm L and N before wiring is recommended.
2. Don’t remove too much of the insulation cover from
the wire to avoid short circuit caused by the naked
wire touching the metal 86 size mounting wall box.
3. Don’t let the screw press or touch the wire when
using screws to x room thermostat in wall box. A
short-circuit risk exists if the wire insulation cover is
damaged by the screw, and if the naked wire con-
nects with the screw.
4. If walls must be painted, mount the room thermo-
stat after painting, to avoid dust or paint material
penetrating the room thermostat and thus damag-
ing the PCB.
5. The max. load of relay is 3 A (resistive) or 1 A (induc-
tive, such as pump or motor). The relay will be dam-
aged if the load exceeds the limit.
6. Don’t cover the thermostat, for instance by hanging
towels directly in front of it.
7. The room thermostat should be connected to the
corresponding loop actuator in individual room
temperature control.
