6.4.8 301-** AF Readouts
Par. No. # Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
301-0* Output Currents
301-00 Output current [A] 0.00 A All set-ups TRUE -2 Int32
301-01 Output current [%] 0.0 % All set-ups TRUE -1 Int32
301-1* Unit Performance
301-10 THD of current [%] 0.0 % All set-ups TRUE -1 Uint16
301-12 Power factor 0.00 N/A All set-ups TRUE -2 Uint16
301-13 Cosphi 0.00 N/A All set-ups TRUE -2 Int16
301-14 Leftover currents 0.0 A All set-ups TRUE -1 Uint32
301-2* Mains Status
301-20 Mains current [A] 0 A All set-ups TRUE 0 Int32
301-21 Mains frequency 0 Hz All set-ups TRUE 0 Uint8
301-22 Fund. mains current [A] 0 A All set-ups TRUE 0 Int32
Programming Instruction Manual
118 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
