1 Lifting holes for the filter
2 Lifting holes for the adjustable frequency drive
Figure 3.7 Recommended Lifting Method, Frame Size F18
NOTICE!
A spreader bar is also an acceptable way to lift the F-
frame.
NOTICE!
The F18 pedestal is packaged separately and included in
the shipment. Mount the adjustable frequency drive on
the pedestal in its final location. The pedestal allows
proper airflow and cooling.
Installation Instruction Manual
MG37A222 Danfoss A/S © Rev. 2014-02-07 All rights reserved. 19
3 3
