[30] Brake fault
(IGBT)
Output is logic ‘1’ when the brake IGBT is
short-circuited. Use this function to protect
the adjustable frequency drive if there is a
fault on the brake modules. Use the
output/relay to cut out the line voltage
from the adjustable frequency drive.
[31] Relay 123 Relay is activated when control word [0] is
selected in parameter group 8-**
Communications and Options.
[32] Mechanical
brake control
Enables control of an external mechanical
brake, see description in chapter 6.1.3 2-2*
Mechanical Brake.
[33] Safe stop
activated (FC
302 only)
Indicates that the safe stop on terminal 37
has been activated.
[40] Out of ref
range
Active when the actual speed is outside
settings in 4-52 Warning Speed Low to
4-55 Warning Reference High.
[41] Below
reference low
Active when actual speed is below speed
reference setting.
[42] Above
reference high
Active when actual speed is above speed
reference setting
[43] Extended PID
Limit
[45] Bus Ctrl Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. The output state is retained in the
event of bus timeout.
[46] Bus Ctrl On at
timeout
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. If bus timeout, the output state is
set high (On).
[47] Bus Ctrl Off at
timeout
Controls output via bus. The state of the
output is set in 5-90 Digital & Relay Bus
Control. If bus timeout, the output state is
set low (Off).
[51] MCO
controlled
Active when an MCO 302 or MCO 305 is
connected. The output is controlled from
option.
[55] Pulse output
[60] Comparator 0
See parameter group 13-1* Comparators. If
comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[61] Comparator 1
See parameter group 13-1* Comparators. If
comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2
See parameter group 13-1* Comparators. If
comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[63] Comparator 3
See parameter group 13-1* Comparators. If
comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[64] Comparator 4
See parameter group 13-1* Comparators. If
comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[65] Comparator 5
See parameter group 13-1* Comparators. If
comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[70] Logic Rule 0
See parameter group 13-4* Logic Rules. If
logic rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1
See parameter group 13-4* Logic Rules. If
logic rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2
See parameter group 13-4* Logic Rules. If
logic rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3
See parameter group 13-4* Logic Rules. If
logic rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4
See parameter group 13-4* Logic Rules. If
logic rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5
See parameter group 13-4* Logic Rules. If
logic rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[80] SL Digital
Output A
See 13-52 SL Controller Action. The output
goes high whenever the smart logic action
[38] Set dig. out. A high is executed. The
output goes low whenever the smart logic
action [32] Set dig. out. A low is executed.
[81] SL Digital
Output B
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[39] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [33] Set dig. out. A low is executed.
[82] SL Digital
Output C
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[40] Set dig. out. A high is executed. The
input goes low whenever the Smart Logic
Action [34] Set dig. out. A low is executed.
[83] SL Digital
Output D
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[41] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [35] Set dig. out. A low is executed.
[84] SL Digital
Output E
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[42] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [36] Set dig. out. A low is executed.
[85] SL Digital
Output F
See 13-52 SL Controller Action. The input
goes high whenever the smart logic action
[43] Set dig. out. A high is executed. The
input goes low whenever the smart logic
action [37] Set dig. out. A low is executed.
Programming Instruction Manual
70 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
