2.8 Installation principle, DHP-H, DHP-C
The image shows the principles of a piping installation with all components.
Figure 9: Principle solution for a piping installation.
Figure 10: Principle solution for a brine installation.
Safety valve
Pressure gauge
Filler tap
HW = Hot water
CW = Cold water
Exp = Expansion
HW
Expansion
tank
To
outlet
Supply pipe
Return pipe
Safety valve, 9 bar
cold water
CW
Exp
Shut-off valve and
strainer
Safety valve, 3 bar
Bleed and
expansion tank
Filling kit incl.
strainer
Shut-off valve
Strainer
Brine in
Brine out
Flexible hoses
