Danfoss ECL Comfort A315 Installation Guide

InstallationGuideECLComfort210/310,applicationA214/A314
A314.1

Heatingand(passive)coolingwithairducttemperature
control































 
TypicalA314.1application:
S 4
M2
S 5
M1
X3
S 3
A
F1
S 2
S 1
Da nfos s 87 H213 3.1 2
P 2
ECL 310
A1
S 6
S 7
S 8
S 8
S 8
+ ECA 32



Listofcomponents:
ECL310
ElectroniccontrollerECLComfort310
ECA32
Built-inextensionmodule
S1
Outdoortemperaturesensor
S2
(Optional)Compensationtemperaturesensor
S3
Flowtemperaturesensor
S4Ducttemperaturesensor
S5
(Optional)Returntemperaturesensor
S6
(Optional)Frosttemperaturesensor
S7
(Optional)Frostthermostat
S8
(Optional)Firethermostat
F1
Fan(ON/OFF)
P2
Damper(ON/OFF)
X3
Circulationpump,heating(ON/OFF)
M1
Motorizedcontrolvalve,heating(3-pointcontrolled)
M2
Motorizeddamper(0-10voltcontrolled)
A1
Alarm



