Danfoss ERC 113D User Manual

User manual ERC 113 refrigeration controller
ERC 113D
Controller 080G3253
ERC 113C
Controller 080G3252
Typical applications
No-frost freezer/sub-zero cooler
Glass door merchandiser
Lights
Fan
DO4DO3
DO1
DO2
1 5432 6
ERC 113D
Controller
DO’s
L
Compressor
N
100 –240VAC SMPS
Defrost Heater
Door Switch
diS1 S2 S3AI/DI’s S4
Door Switch
diS1 S2 S3AI/DI’s S4
Lights
Fan
DO3
DO1
DO2
1 5432
ERC 113C
Controller
DO’s
L
Compressor
N
100 – 240VAC SMPS
Temperature Sensor for Cabinet
Temperature Control
Temperature Sensor for Evaporator
Temperature Control
Remote spindle Door input
PVC Standard
Connector type (S1) 3-pole
PVC Standard
Connector type (S2) 2-pole
Remote spindle
Door sensor cable
di/S4 3-pole
Magnetic door sensor
di/S4 3-pole
470 mm 077F8751 1000 mm 077F8786 1000 mm 080G3371 1000 mm 080G3340 1000 mm 080G3320
1000 mm 077F8757 1500 mm 077F8790 2000 mm 080G3373 2000 mm 080G3341 2000 mm 080G3322
1500 mm 077F8761 2000 mm 077F8794 3000 mm 080G3375 3000 mm 080G3342 3000 mm 080G3324
2000 mm 077F8765 3000 mm 077F8798 4000 mm 080G3343
2200 mm 077F8767 6000 mm 080G2029
3000 mm 077F8769
3500 mm 077F8723
6000 mm 080G2019
Temperature Sensor for Cabinet
Temperature Control
Temperature Sensor for Evaporator
Temperature Control
Remote spindle Door input
PVC Standard
Connector type (S1) 3-pole
PVC Standard
Connector type (S2) 2-pole
Remote spindle
Door sensor cable
di/S4 3-pole
Magnetic door sensor
di/S4 3-pole
470 mm 077F8751 1000 mm 077F8786 1000 mm 080G3371 1000 mm 080G3340 1000 mm 080G3320
1000 mm 077F8757 1500 mm 077F8790 2000 mm 080G3373 2000 mm 080G3341 2000 mm 080G3322
1500 mm 077F8761 2000 mm 077F8794 3000 mm 080G3375 3000 mm 080G3342 3000 mm 080G3324
2000 mm 077F8765 3000 mm 077F8798 4000 mm 080G3343
2200 mm 077F8767 6000 mm 080G2029
3000 mm 077F8769
3500 mm 077F8723
6000 mm 080G2019
26
DKRCC.ES.RL0.F5.02 Produced by Danfoss A/S (ADAP-KOOL®) | 2016-07
