FP735SI
4
GBGB
Timer Features FP735Si
Power supply 230V ±15%, 50Hz
Memory backup Retained for the life of the product
Factory set calendar clock Automatic summer/winter time change
Switching action of output relay 3 x SPDT, Type 1B
Switch rating of relay contact 3(1) A, 230 VAC
Rated Impulse Voltage 2.5 kV
Dimensions (mm) 140 wide x 91 high x 29 deep
Ball Pressure Test 75°C
Design Standard EN 60730-2-7
Control Pollution Situation Degree 2
Time accuracy ± 1 minute per month
IP rating IP30
Software Classi cation A
2.0 System Overview
Please Note:
This product should only be installed by a quali ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.
1.0 Installation Guide
