Danfoss FT1330 Crimp Machine Operator’s Manual
34 | © Danfoss FT1330 Crimp Machine Operator’s Manual | 2023.02.
AQ439269212774en-000101
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
45 **FT1330-2-10 1/4-20 x 1.00 Soc Hd Cap Screw 4
46 FT1330-3-36 Star Washer .25 I.D. 8
47 FT1330-3-37 Hex Nut (1/4-20) 2
48 FT1330-3-38 Lock Washer (.32 I.D.) 4
49 FT1330-3-39 Hex Nut (5/16-18) 4
53 FT1330-3-43 Shipping Crate 1
54 FT1330-3-30 Crimp Diameter Decal - Barrel Field Crimp 1
54A FT1330-3-73 Crimp Diameter Decal - Flat Field Crimp 1
55 FT1330-3-9 Cover 1 *
56 SC2307 Name Plate 1
57 FT1330-3-41 #4 Drive Screw 4
58 FT1092 Never Seeze Lube 1
59 FT1330-2-5 Electronic Subassembly 1
60 FT1330-3-60 Locator Collar 1
61 FT1330-3-61 Spring Plunger RCID XNK1A-N 2
62 FT1330-3-62 Aluminum Plate 1
63 FT1330-3-63 #8-32 x .62 Lg. Flat Hd Cap Screw 2
64 FT1330-3-64 Caution Decal 1
65 FT1242-3-27 Cable 1
66 FT1242-3-28 Ferrule 1
67 FT1330-3-67 Dust Cover (Optional) 1
68 FT1330-3-68 Light (Optional) 1
69 FT1330-3-72 ORS Decal 1
**Supplied as a complete fastener kit only.
FT1330-2-2 Power Unit
PART NUMBER DESCRIPTION NUMBER REQUIRED
FT1330-2-2-1 Motor 1
FT1330-2-2-2 Manifold 1
FT1330-2-2-3 Valve 1
FT1330-2-2-4 Reservoir 1
FT1330-2-2-5 Pump 1
FT1330-2-2-6 Bolt Kit 1
FT1245-3-1 Breather Cap 1
FT1330-2-2-9 Seal Kit 1
