Crimp Die Cage
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-9-9 1/4-20 X 2.50 Screw 1
2 FT1330-2-9-2 Spring 8
3 FT1330-2-9-3 Spring Plate 1
4 FT1330-2-9-4-1-1 Front Plate 1
5 FT1330-2-9-5 1/4-20 x 2.00 Screw 3
6 FT1330-2-9-6 Spacer 4
7 FT1330-2-9-7 Nut 1
8 FT1330-2-9-8 Back Plate 1
