Barrel Crimp Die Cage
FT1330-2-9-51
DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED
1 FT1330-2-9-1 Roll Pin 8
2 FT1330-2-9-2 Spring 8
3 FT1330-2-9-3 Spring Plate 1
4 FT1330-2-9-4-2 Front Plate 1
5 FT1330-2-9-5 Button Head Cap Screw 3
6 FT1330-2-9-6 Spacer 4
7 FT1330-2-9-7 Nut 1 -
8 FT1330-2-9-8 Back Plate 1
9 FT1330-2-9-9 Button Head Cap Screw 1
11 FT1330-2-9-10 Button Head Cap Screw 2
12 FT1330-2-9-11 Lock Nut 2
13 FT1330-250-0016 Locator Tab 1
13 FT1330-250-0012 Locator Tab 1
14 FT1330-2-9-12 Bumper Grommet 2
17 FT1330-275-12 Locator Tab Adapter 1
18 FT1330-285-16 Locator Tab Adapter 1
