Danfoss FT1330 Crimp Machine Operator’s Manual

52 | © Danfoss FT1330 Crimp Machine Operator’s Manual | 2023.02.

AQ439269212774en-000101

DETAIL NUMBER PART NUMBER DESCRIPTION NUMBER REQUIRED

1 FT1330-2-9-1 Roll Pin 8

2 FT1330-2-9-2 Spring 8

3 FT1330-2-9-3 Spring Plate 1

4 FT1330-2-9-4-1 Front Plate 1

5 FT1330-2-9-5 Button Head Cap Screw 3

6 FT1330-2-9-6 Spacer 4

7 FT1330-2-9-7 Nut 1

8 FT1330-2-9-8 Back Plate 1

9 FT1330-2-9-9 Button Head Cap Screw 1

11 FT1330-2-9-10 Button Head Cap Screw 3

12 FT1330-2-9-11 Lock Nut 3

13 FT1330-250-0010 Locator Tab 1

14 FT1330-2-9-12 Bumper Grommet 3

13 FT1330-250-0608 Locator Tab 1

13 FT1330-250-0004 Locator Tab 1

15 FT1330-275-12 Locator Tab Adapter 3

Barrel Crimp Die Cage

FT1330-2-9-52
