Axial and radial ports dimensions, mm [in]
Measure
Size 060 Size 080 Size 110 Size 160
AA
188.1 [7.41] 187.5 [7.38] 201.9 [7.95] 229.3 [9.03]
AB
164.7 [6.48] 170.6 [6.72] 175.0 [6.89] 183.8 [7.24]
AC
167.5 [6.59] 179.9 [7.08] 196.9 [7.75] 219.7 [8.65]
BA
120.6 [4.75] 116.4 [4.58] 125.8 [4.95] 149.6 [5.89]
BB
32.3 [1.27] 34.7 [1.37] 37.5 [1.49] 42.0 [1.65]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.50] 99.9 [3.93]
BD
106.8 [4.20] 101.5 [4.00] 112.4 [4.43] 133.6 [5.26]
BE
84.0 [3.30] 92.4 [3.64] 102.5 [4.04] 115.4 [4.54]
BF
43.0 [1.69] 37.0 [1.46] 46.0 [1.81] 64.0 [2.52]
BH
120.6 [4.75] 116.4 [4.58] 125.8 [4.95] 149.6 [5.89]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
BL
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CA
159.5 [6.28] 156.3 [6.15] 168.1 [6.62] 192.6 [7.58]
CB
43.4 [1.71] 46.2 [1.82] 49.6 [1.95] 54.4 [2.14]
CC
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CD
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CF
32.2 [1.27] 31.0 [1.22] 34.1 [1.34] 51.8 [2.04]
CG
44.0 [1.73] 56.8 [2.24] 55.0 [2.17] 50.0 [1.97]
CH
75.0 [2.95] 78.0 [3.07] 86.0 [3.39] 97.0 [3.82]
CJ
44.2 [1.74] 36.0 [1.42] 38.1 [1.50] 52.8 [2.09]
CK
35.0 [1.38] 46.0 [1.81] 47.9 [1.89] 51.0 [2.01]
CL
26.1 [1.03] 21.5 [0.85] 22.9 [0.90] 25.1 [0.99]
CM
74.8 [2.94] 74.4 [2.93] 79.0 [3.11] 87.7 [3.45]
CN
160.6 [6.32] 156.3 [6.15] 169.1 [6.66] 193.6 [7.62]
CO
43.7 [1.72] 46.2 [1.82] 49.9 [1.96] 54.6 [2.15]
CP
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CR
68.4 [2.69] 68.2 [2.69] 70.4 [2.77] 74.4 [2.93]
α
25°
For further detailed information about Cartridge ports dimensions see the Cartridge flange design ports
per ISO 11 926-1 on page 116.
Legend:
1 Loop flushing relief valve
2 Loop flushing shuttle spool
3 Speed sensor
4 Minimum angle stop adjustment
5 Connector: DT04-2P
6 Alternate position of case drain port
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 111
