Two-position solenoid data C5 (Brake Pressure Defeat) (continued)
Description 12 V 24 V
IP Rating (IEC 60 529) IP 67
IP Rating (DIN 40 050) with mating connector IP 69K
H1B control response
H1 controls are available with orifices to assist in matching the rate of stroking time from maximum
displacement (100 %) to minimum displacement (20 %) and vice versa to application requirements.
Stroking times for other pressure levels could be calculated at simulation model of request.
Typical response times shown below at the following conditions:
System and charge pressure = 210 bar [3046 psi] and 20 bar [290 psi]
Viscosity and temperature = 20 mm²/s [97 SUS] and 60°C [140°F]
Speed = 1500 min
-1
(rpm)
H1B typical response times
Orifice Stroking
direction
Size
060 080 110 160
210
250
Ø0.6 mm
[Dia 0.02 in]
Max. to min. 0.70 s 1.04 s 1.31 s 1.97 s
2.15 s
2.21 s
Min. to max. 0.75 s 1.04 s 1.41 s 2.03 s
2.23 s
2.30 s
Ø0.8 mm
[Dia 0.03 in]
Max. to min. 0.41 s 0.61 s 0.76 s 1.14 s
1.25 s
1.28 s
Min. to max. 0.44 s 0.60 s 0.81 s 1.16 s
1.27 s
1.31 s
Ø1.2 mm
[Dia 0.05 in]
Max. to min. 0.22 s 0.32 s 0.40 s 0.59 s
0.65 s
0.67 s
Min. to max. 0.24 s 0.32 s 0.43 s 0.60 s
0.66 s
0.69 s
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Controls – nomenclature, description
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 89
