Axial and radial ports dimensions, mm [in]
Measure
Size 060 Size 080 Size 110 Size 160
AA
180.8 [7.12] 180.8 [7.12] 196.5 [7.74] 225.4 [8.87]
AB
114.7 [4.52] 119.4 [4.70] 130.8 [5.15] 138.2 [5.44]
AC
224.2 [8.83] 235.7 [9.28] 247.2 [9.73] 265.0 [10.43]
BA
120.6 [4.75] 116.4 [4.58] 125.8 [4.95] 149.6 [5.89]
BB
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.50] 99.9 [3.93]
BE
32.0 [1.26] 27.0 [1.06] 36.0 [1.42] 56.0 [2.20]
BF
136.3 [5.37] 134.3 [5.29] 148.9 [5.86] 174.9 [6.89]
BG
18.9 [0.74] 22.0 [0.87] 24.8 [0.98] 28.6 [1.13]
BH
126.6 [4.75] 116.4 [4.58] 125.8 [4.95] 149.6 [5.89]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
BL
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CA
159.9 [6.30] 156.3 [6.15] 168.1 [6.62] 192.6 [7.58]
CB
43.3 [1.71] 46.2 [1.82] 49.6 [1.95] 54.4 [2.14]
CC
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CD
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
CF
32.2 [1.27] 31.0 [1.22] 34.1 [1.34] 51.8 [2.04]
CG
44.0 [1.73] 56.8 [2.24] 55.0 [2.17] 50.0 [1.97]
CH
75.0 [2.95] 78.0 [3.07] 86.0 [3.39] 97.0 [3.82]
CJ
44.2 [1.74] 36.0 [1.42] 38.1 [1.50] 52.8 [2.09]
CK
35.0 [1.38] 46.0 [1.81] 47.9 [1.89] 51.0 [2.01]
CL
26.1 [1.03] 21.5 [0.85] 22.9 [0.90] 25.1 [0.99]
CM
74.8 [2.94] 74.4 [2.93] 79.0 [3.11] 87.7 [3.45]
CN
160.6 [6.32] 156.3 [6.15] 169.1 [6.66] 193.6 [7.62]
CO
43.7 [1.72] 46.2 [1.82] 49.9 [1.96] 54.6 [2.15]
CP
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
CR
68.4 [2.69] 68.2 [2.69] 70.4 [2.77] 30.0 [1.18]
α
25°
For further detailed information about Cartridge ports dimensions see the Cartridge flange design ports
per ISO 11 926-1 on page 116.
Legend:
1 Loop flushing relief valve
2 Loop flushing shuttle spool
3 Speed sensor
4 Minimum angle stop adjustment
5 Connector: DT04-2P
6 Alternate position of case drain port
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 113
