Q – PCOR pressure setting
00 For all controls without PCOR function 23 230 bar [3336 psi]
16 160 bar [2321 psi] 24
*
240 bar [3481 psi] – Standard setting
17 170 bar [2466 psi] 25 250 bar [3626 psi]
18 180 bar [2611 psi] 26 260 bar [3771 psi]
19 190 bar [2756 psi] 27 270 bar [3916 psi]
20 200 bar [2901 psi] 28 280 bar [4061 psi]
21 210 bar [3046 psi] 29 290 bar [4206 psi]
22 220 bar [3191 psi] 30 300 bar [4351 psi]
*
Standard setting at production test for P* controls:
•
800 mA for P1
•
400 mA for P2
R – Paint and nametag
NNN Black paint and Nametag
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Master Model Code
©
