Proportional solenoid data C1
Description 12 V 24 V
Maximum current
1800 mA 920 mA
Nominal coil resistance @ 20 °C [68 °F]
3.66 Ω 14.20 Ω
@ 80 °C [176 °F]
4.52 Ω 17.52 Ω
Inductance
33 mH 140 mH
PWM Range
70-200 Hz
Frequency (preferred)
*
100 Hz
IP Rating IEC 60 529
IP 67
DIN 40 050, part 9
IP 69K with mating connector
Connector color
Black
*
PWM signal required for optimum control performance.
Two-position solenoid data C5 (Brake pressure defeat)
Description 12 V 24 V
Min. supply voltage
9.5 V
DC
19 V
DC
Max. supply voltage (continuous)
14.6 V
DC
29 V
DC
Nominal coil resistance @ 20 °C [68 °F]
8.4 Ω 34.5 Ω
Recommended input current
1050 mA 500 mA
IP Rating
IEC 60 529
IP 67
DIN 40 050, part 9
IP 69K with mating connector
Bi-directional diode
yes
Connector color
Blue
W
Warning
Zero degree capability results in a high risk of overspeed and drops in efficiency if the motor operates
between 0–20% displacement.
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Controls – nomenclature, description
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 47
