Danfoss iC7 Series User Manual

Selection number
Selection name
7
Resolver A,B
8
Resolver A,B + mirror out Z,D
9
Resolver A,B + 2 track incremental Z,D
10
SinCos A,B
17
SSI Z,D
19
SSI Z,D + 2 track incremental A,B
33
SSI with 2 track incremental Z,D,A,B
34
SSI with SinCos Z,D,A,B
22
EnDat Z,D
23
EnDat Z,D + 2 track incremental A,B
25
HIPERFACE A,B,D
26
HIPERFACE DSL D
27
HIPERFACE DSL D + 2 track incremental A,B
29
BiSS Z,D
30
BiSS Z,D + 2 track incremental A,B
31
BiSS with 2 track incremental Z,D,A,B
32
BiSS with SinCos Z,D,A,B
P 9.4.2 Encoder Supply Voltage
Description: Set the supply voltage level according to the specifications of the connected encoder.
Default Value : 5
Parameter Type: Range (3 — 24)
Parameter Number: 4002
Unit: V
Data Type: UINT
Access Type: Read/Write
P 9.4.3 Supply Sense
Description: Enable power supply cable drop compensation.
Default Value : 0 [Disabled]
Parameter Type: Selection
Parameter Number: 4035
Unit: -
Data Type: BOOL
Access Type: Read/Write
The following are the selections for the parameter.
Selection number
Selection name
0
Disabled
1
Enabled
P 9.4.4 Invert Direction Channel 1
Description: Select if signal on channel 1 shall be inverted. For dual output channel encoders this parameter affects the entire en-
coder information (absolute and incremental part).
Default Value : 0 [Disabled]
Parameter Type: Selection
Parameter Number: 4092
Unit: -
Data Type: BOOL
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 39Danfoss A/S © 2023.06
Encoder/Resolver Installation and
Configuration
Functional Extension Options
Operating Guide
